Board Extension Cylinder

The board extension cylinder is a core hydraulic actuator used in mechanical manufacturing, mold processing, and automated production lines to drive the board to achieve the extension and contraction motion. Its core functions revolve around precise extension of the sample, stable support, and flexible adaptation.

  • Ød(mm)
    35-85
  • ØD(mm)
    45-110
  • S(mm)
    100-300
  • L(mm)
    500-1500
  • PRESSORE (Mpa)
    10-21
Specifications

 Bore range 65-110mm, rod range 35-85mm, length 500-1500mm, operating pressure 21MPa, maximum thrust up to 20T.

Benefits & Features

Product Advantages: High-precision positioning, high load capacity, compact structure, stable and reliable quality, and extremely high cost-effectiveness.

Application Industry: Paving machines
